concerts and culinary delights Markus Stenger from Stenger2 Architekten und Partner , Munich says: «The decisive factors for choosing Janisol Arte 2.0 were the small cross-section, the very high-quality surface [...] metres wide and 16 metres high; in the area of the entrance doors, the total height is 18 metres. Stenger2 Architekten und Partner mbB BDA , Müchen/DE Metallbau Knöpfle GmbH , Krumbach/DE DE-Munich

plate is easy to fit. The top locking mechanism required for sash heights > 2,300 mm originally comes from the Janisol Arte 2.0 system and was specially developed to ensure that the contact pressure is [...] together to create a homogeneous appearance. This means that both doors with burglary protection up to RC2 and doors without burglary protection can now be installed in a single room with no visual difference [...] motorized version is used. Special shapes are possible on request (e.g. a round arch). Doors from the Janisol system can be produced with CE marking up to a height of 3,000 mm. It goes without saying that all

travelling. In the facade, the slender elegance of the original design language is taken up by the Janisol Arte 2.0 profile design. Valle Arquitectos , Madrid/ES SGA – Grupo Teofilo , Madrid/ES ES-Madrid

“contemporary response to the neighbouring Gründerzeit building”. Thanks to the equally contemporary Janisol Arte 2.0 steel profile, it was possible to realise the Argus eyes on the building in the filigree style [...] desired by the architect. Metallbau Sauritschnig was able to make this idea reality thanks to Janisol Arte 2.0 , the narrowest thermally separated steel profile available on the market. The window elements [...] ed with rounded corners was another challenge that Sauritschnig mastered with ease thanks to Janisol Arte 2.0 – the profile can also be bent easily. Zaha Hadid Architects , London/GB Architekt DI Martin

slender Janisol Arte 2.0 steel profile system transforms, as fixed glazing, properties in various assembly situations and with a variety of opening types into style icons. With the new Janisol Arte 66

heritage building while at the same time adapting it to today's energy requirements – thanks to Janisol Arte 2.0 , among other things: “The steel system enabled us to retain the original proportions while

industrial heritage building while at the same time adapting it to today's energy requirements. Janisol Arte 2.0 was the optimal solution to replicate the Crittall-style single glazed 1930s/50s windows originally

Folding and sliding systems VISS Facade Janisol HI door Janisol folding partition Janisol lift-and-slide door Fire doors and fire-resistant partitions – Janisol 2 Prof. Heike Hanada, laboratory of art and

Custom curved steel profiles and tubes

Christoph Kruse from GRS Reimer Architekten, explaining the special construction made using the Janisol Arte 2.0 steel profile system. “This makes the window seem even more slender.” The profiles were po

tests the resistance of various building components and puts them in resistance classes RC 1 N, RC 2 N and RC 2 to RC 6. The N in the first two categories refers to the possibility of certain aspects being [...] House Jansen Economy 60 (possible until RC3 ) JVA Cazis Tignez Jansen Economy 60 und Fire door Janisol 2 EI30 in R3 Products burglar resistance Doors Windows Facades Folding and sliding doors Downloads [...] experience. Video burglar resistance Selecting the appropriate level of resistance In the private sphere, RC2 is recommended as the minimum requirement. This resistance class provides protection against break-in

planners appreciate about the steel profile systems from Jansen. Unlike almost all other systems, the Janisol 2 system meets the highest demands in terms of design freedom and structural safety in just one profile [...] function. With a clearance of up to 1500 x 3000 mm (single-leaf) or 3000 x 3000 mm (double-leaf), Janisol 2 multi-functional doors are suitable for use in all kinds of public buildings. Equipped with an [...] at 1500 mm or 3000 mm, thus ensuring barrier-free access in the design without a doorsill. The Janisol 2 steel profile system has been approved for use throughout Europe in accordance with EN 16034. Its

Atelier RUA Arquitectos , Lisbon/PT Tecnosece, Lda, Pombal/PT Janisol Arte 2.0 as door systems PT-Olhão

company, an unusually high level of sustainability was realised for an old building. The choice of Janisol Arte 2.0 steel windows , which preserve the protected exterior of the building, also contributes to

Category: Fixed window Manufacturer: Jansen AG Product name: Janisol HI Festverglasung

RISCO. Various Jansen systems were used in this project, with Janisol and Janisol Arte2.0 predominating, but the fire-resistant system Janisol 2 EI30 came also into use. The object was the winner in the category

× 3190 mm (W × H) Leaf weight up to 180 kg Burglar resistance RC2 Zero threshold possible, including for RC2 → Discover the Janisol Arte 2.0 door now Orders possible from: December 2024 Do you have a suitable [...] fixed glazing → Discover Janisol Arte 66 windows now Orders possible from: presumably fall 2025 Do you have a suitable project? Contact us now! Oversized designer door - Janisol Arte 2.0 Plus The Plus solutions [...] a suitable project? Contact us now! Filigree lift and slide door - Janisol Arte 66 With the extension of the proven, filigree Janisol Arte 66 system to include a lift-and-slide system, the transition between

users Make wishes come true Design for practitioners Implementing planning security Productdesign Janisol Arte 2.0 door

facade are covered, among other things, by a mullion-transom facade made of VISS Fire Facade EI30 . Janisol 2 EI 30 fire doors and Jansen-Economy 50 profiles are the ideal complement. Nickl & Partner Architekten

band with staggered opening ventilation sashes. The Janisol steel profile system in the form of the Janisol HI window elements used as well as Janisol 2 EI30 fire protection sliding doors cover the requirements [...] with staggered ventilation sashes for opening. With this in mind, the Janisol steel profile system – seen here in the form of the Janisol HI window elements – meets the special requirements of the building [...] envelope of a research building. Boltshauser Architekten , Zurich/CH Aepli Metallbau AG , Gossau/CH Janisol C4 fire dampers CH-Zurich

Emergency Housing The oversized windows were each designed with a rounded corner. These are based on Janisol Arte 2.0 window steel profiles, which were each manufactured by Lootens to room height and in special

Smoke and fire doors and glazing

Reconstructed windows - Janisol Arte 2.0 The building features a variety of window formats, including large sectioned windows that extend across the entire height of the hall. Glaskunst Buhlig produced

archives of the fortress, the existing composite windows were replaced by mullioned windows made of Janisol Arte 2.0 . In order to preserve the appearance of the building as best as possible, the panes were sealed [...] make 20 mullioned windows with ventilation sashes. "Thanks to the excellent profile properties of Janisol Arte and our technical know-how for special constructions, the original windows could be recreated

cladding made from heat-insulating trapezoidal sheets, a new window layout made from the narrow Janisol Arte 2.0 steel profiles, and no shortage of passion and commitment from the operators, the dream property

mullion-transom façade made of steel provides 60 minutes of fire resistance around the atrium. Janisol 2 EI30 and Janisol C4 EI60 steel fire doors are integrated into this. Numerous Schüco Alumnium systems, such

interior of the building. Intricate refurbishment profiles With a large variety of opening types, Janisol Arte 2.0 is just as ideal for the refurbishment of historic windows as it is for windows in trendy new

second glance. The large windows were faithfully reconstructed using the thermally separated Janisol Arte 2.0 steel profile system and structurally reinforced. OPB Obermeyer Planen + Beraten , Berlin/DE

The Janisol 2 EI30 anti-finger-trap fire doors reduce the potential risk of injury at the secondary closing edge to a minimum thanks to rounded half shells. They are therefore particularly suitable for [...] size, double door: 3000 × 3000 mm Also available as fire doors and fire-resistant partitions – Janisol 2 EI30 Test certificates Fire resistance EI30 to EN 1634-1 and DIN 4102-5 Smoke control in accordance [...] Emergency exit door in accordance with EN 1125 / EN 179 Finger protection to DIN 18650-1, DIN 18650-2 and EN 16005

up to 2.5 m with single-latch lock Door height up to 3.0 m with single-latch lock and bi-metal lug or single-latch lock with top retracting bolt Also available as anti-finger-trap door Janisol 2 EI30 Test [...] The Janisol 2 fire protection system fulfils the requirements for safety and design freedom in buildings like no other system. The material properties of steel make it possible to create very strong and [...] anti-panic doors that also meet all of the requirements set out in EN 16034. The highly heat-insulating Janisol 2 fire protection doors allow for complete automation and people are thus able to walk through the

door profiles in the proven fire protection system Janisol 2 EI30 have been expanded with the installation depth 70 mm. In this way transparent Janisol C4 EI60 fire-resistant partitions - in the extreme [...] extreme case even EI90 fire-resistant partitions- can be combined with Janisol 2 EI30 without problems. Material / surface finish Uncoated or strip-galvanised steel, suitable for powder coating or stove-enamelling [...] features Dry glazing or glazing with putty Central glazed panel sheet metal clad doors Door height up to 2.5 m with single-latch lock Door height up to 3.0 m with single-latch lock and bi-metal lug or single-latch

The comprehensive sliding fire door system, with its particularly slender frame profiles, appeals in terms of function as well as aesthetics. The door profile system has been successfully tested under

New developments and innovations for the Janisol Arte system

various lock versions, a wide range of materials – namely steel, stainless steel and Corten steel). Janisol Arte 2.0 doors are therefore the right choice for renovations to existing buildings and modern structures [...] C5/B5 (2000 Pa) Airborne sound insulation up to Rw 45 db Heat transmission coefficient UD > 1.9 W/m2K Shear coupling in accordance with EN 14024 Mechanical strength in accordance with EN 13115 up to Class

profile system Janisol Arte, extremely large sliding doors with slim face widths and high stability can be prepared. Originally developed by Jansen for the reconstruction of historic windows, Janisol Arte now [...] to 3000 × 2500 mm (W×H) Max. weight 150 kg/leaf Insulating glass from 20 to 34 mm UW value of 1.5 W/m2K Welded steel profile half shells in combination with glass-fibre reinforced high-performance plastics

steel window system for matching the existing style in refurbishments The second generation of the Janisol Arte window system now offers profiles made from stainless steel and Corten steel as well as a wide [...] Watertightness up to class 9A (600 Pa) Sound reduction up to 45 dB Thermal transmittance of Uf from 1.9 W/m2K Air permeability class 4 (600 Pa) Load-bearing capacity of safety devices met Mechanical strength class [...] safety barrier loading DIN 18008-4 met Burglar resistance tested in accordance with EN 1627 up to RC2

Janisol Arte 2.0 door Extremely slim face widths and outstanding performance values are the hallmarks of the Janisol Arte 2.0 thermally separated steel system, which has previously been used to manufacture [...] system and the Jansen Art'System window system. Janisol Arte 2.0 door Doors made of steel, stainless steel and Corten steel with narrow face widths Janisol Arte 2.0 window Slender steel window system for matching [...] Design and functionality Dimensions Range of applications Janisol Arte family Materials References Performance values Contact Janisol Arte 2.0 Webinar Register now to receive the recording of the webinar:

usual way, as with the Janisol and Janisol Arte 2.0 steel profiles – this ensures a high level of process reliability. Benefits Modern opening type Compatible with Janisol Arte 2.0 Concealed fitting Free [...] Slim tilt and turn windows made from steel profiles With Janisol Arte 66, Jansen is expanding its range of systems to include an attractive variation. The basic depth of 66 mm enables the use of stronger [...] Watertightness up to class 9A (600 Pa) Sound reduction up to 47 dB Thermal transmittance of Uf from 1.9 W/m2K Air permeability class 4 (600 Pa) Load-bearing capacity of safety devices met Mechanical strength class

lightweight partition wall Central glazed panel Dry glazing and glazing with putty Door heights up to 2.50 m with single-latch lock Test certificates Fire resistance classes EI60 and EI90 tested in accordance

also increasingly observed in the private sector. Burglar resistance with RC2 classification is often sufficient here, as RC2 offers protection for up to three minutes. Only a few additional parts are required [...] centres and the like. Stainless steel adds a graceful look and reduces maintenance to a minimum. Janisol stainless steel is therefore the right choice for shopping malls, railway stations, banks and hotels [...] required, which also remain invisible. The elegant appearance of the Janisol door remains eye-catching. Materials/surface finishes Uncoated or strip-galvanised steel, suitable for powder coating or st

The Janisol folding partition is based on the thermally insulated Janisol system and is flexible in use. It can be used as a room divider or for the exterior. The proven system – newly developed for flexible [...] ng glass doors 2 to 6 leaves Inward- and outward-opening Any leaf arrangement Equipment Fittings up to 200 kg Weight of leaf up to 100 kg Leaf widths up to 1'000 mm Leaf heights up to 2'900 mm Special

Strong steel for strong insulation of doors, windows and fixed glazing units

The Janisol HI door system fulfils maximum insulation requirements and, with respect to safety/security and durability, is also suitable for extreme service conditions – such as those in very busy public [...] glazing, it is easy to achieve doors with excellent thermal conductivity coefficients of U d 1.0 W/m2K. Thanks to high-tech thermal break spacer bars made of glass-fibre reinforced plastic, the new door [...] excellent structural values and achieves top values in system tests (air/water/wind/mechanics). With Janisol HI, Jansen sets new benchmarks in terms of contemporary architecture combined with excellent thermal

achieve windows with excellent thermal conductivity coefficients (Uw), e.g. 0.69 W/m2K for fixed lights and 0.8 W/m2K for opening elements. Thanks to high-tech thermal break spacer bars made of glass-fibre [...] insulation up to Rw 46 dB Heat transmission coefficient Uw > 0.69 W/m2K for fixed glazing Heat transmission coefficient Uw > 0.8 W/m2K for windows Shear bonding in accordance with EN 14024 Tests in accordance [...] Janisol HI windows combine aesthetics with refined technology. Slender frame profiles enhance the architectural styling while the innovative technology ensures the best possible thermal separation. With

against heavy rain up to class 6A Air permeability up to class 4 Resistance to wind load up to class C2/B2 Airborne sound insulation up to Rw 39 dB Shear bonding in accordance with EN 14024 [...] The Janisol lift-and-slide door programme re-defines the living room. The proven system, which has been re-developed for large openings, allows the indoors and the outdoors to merge and in this way creates [...] disable access threshold and, on the other hand, also guarantees optimal thermal insulation. The Janisol lift-and slide doors are CE-compliant and have been tested at ift Rosenheim. Materials / surface

environmentally compatible sustainable building. The assembly and manufacture of Janisol Primo and combination with Janisol systems are simplified by the use of identical profile cross sections. Materials [...] class C4 Airborne sound insulation up to Rw 45 dB Coefficient of thermal transmittance Uw > 1.0 W/m2K Shear bonding in accordance with EN 14024 Burglar resistance in accordance with EN 1627 up to RC (WK)

The slender profile face widths of the Janisol windows made of steel or stainless steel provide space for creativity and lend the building a quite special character. Whether it is sash bar variants, arched [...] arched windows or large-element glazing: the Janisol window system is particularly suitable for use in new buildings as well as for the refurbishment of existing buildings. Materials/surface finishes Uncoated [...] class C4 Airborne sound insulation up to Rw 45 dB Coefficient of thermal transmittance Uw > 1.5 W/m 2 K Mechanical strength class 4 Operating forces class 1 Impact resistance class 5 Load-bearing capacity

Customized Solutions Janisol Arte 2.0 Plus Design and safety Extremely narrow face widths and outstanding performance values characterize the thermally broken steel system Janisol Arte 2.0 Plus, which has [...] d doors for exterior and interior use or use French doors. More about the Janisol Arte 2.0 Plus door VISS Fire Facade EI30 RC2/3 Further development: VISS facade system combines fire and burglary protection [...] Fire facade EI30 RC2/3. This development aims to offer multifunctionality by providing both effective fire protection and high burglary protection. More about VISS Fire Facade EI30 RC2/3 Further information

including heavy-duty T connectors Motorised Janisol HI bottom-hung vents Two-leaf, outward-opening VISS side-hung door Automatic VISS sliding door 5 x 4 m Janisol HI doors Commitment to sustainability Lo [...] and optimise internal lighting conditions (SageGlass from Saint Gobain) Downloads Technology Center (2 MB)

widths. The appearance is identical to that of the other fire protection systems Economy 60, Janisol 2 and Janisol C4. Materials / surface Uncoated or strip-galvanised steel, suitable for powder coating or
